RAIN RFID Hardware Solution for Retail, Logistics & Industrial Sectors

Portable Industrial Hybrid Barcode RFID Scanner SkyLink H70

Portable Industrial Hybrid Barcode RFID Scanner SkyLink H70

Core Excellence

Long-Range UHF RFID Scanning: IMPINJ E710 chip, max 15-25m read range

Massive 10,000mAh Battery: 8+ hours continuous operation | 300h+ standby

Military-Grade Ruggedness: 1.5m drop resistance | 1,000 tumbles | IP65

High-Speed Data Capture: Optional 5mil barcode scanner (50 scans/sec) + NFC (3-5cm)

Global Connectivity: 4G LTE multi-band | Dual-band Wi-Fi (2.4G/5G) | BT 5.0 | GPS

Free Sample Now

Features
Parameters

Why Choose Portable Industrial Hybrid Barcode RFID Scanner SkyLink H70?

✓ Future-Proof OS : Android 12 ensures app compatibility & security updates:

✓ Reduced TCO (Total Cost of Ownership): High durability minimizes repairs/replacements

✓ Scalable Data Capture: Modular UHF RFID + Barcode options adapt to workflow needs

✓ Ergonomic Productivity: 5.72" HD touchscreen + glove-friendly Corning Gorilla Glass 3

✓ Global Compliance Ready: Pre-configured for regional frequency regulations

✓ Enhanced Field Visibility: 13MP AF camera with flash for visual documentation

✓ Simplified IT Management: Standard Android deployment & maintenance

Transformative Applications of Rugged Android UHF RFID handheld reader Barcode scanner SkyLink H70

Industry	Key Use Cases	Solutions Enabled
? Warehousing	- Bulk inventory counts - Dock door receiving - Pallet tracking	Automated RFID pallet audits Contactless container verification Real-time stock reconciliation
? Retail	- Smart shelf audits - Omnichannel inventory - Loss prevention	Instant RFID cycle counts E-commerce return processing Security tag deactivation
?️ Manufacturing	- WIP tracking - Tool management - Compliance labeling	RFID-enabled work-in-process monitoring Tool calibration tracking Automated compliance logging
? Logistics	- Yard management - Container verification - Cross-docking	RFID trailer load validation Automated shipping manifests Dock door inventory management
? Healthcare	- Medical device tracking - Pharmacy inventory - Sterile zone audits	Sterilization cycle tracking Medication expiry monitoring Asset utilization analytics
? Field Services	- Utility asset inspections - Construction tool control - Energy meter reads	RFID-based asset condition reporting Tool issuance automation Meter data collection

Specification

Mainboard		Physical
Operating System	Android 12.0	Dimensions	17883150mm
Processor	MTK 6765- Octa-core, 2.3GHz	Weight	N.W.: 580gs/Pc G.W.:1.0-1.2KGS/Box
Memory	RAM 4GB, 64GB expandable	Main material	Engineering Plastic, PCB, ABS, Aluminum, tempered glass
Expandable	Fingerprint sensor for OEM projects	Screen	5.72'' IPS LTPS 1440*720; Multi-touch panel, Corning grade 3 glass toughened screen
Sensors	Optical distance /gravity /gyroscope / geomagnetic	Speaker/Microphone	Bulit-in, 8Ω/0.8W waterproof horn x 1 Sensitivity: -42db, Output impedance 2.2kΩ
NFC		Docking Station	USB type C for charging, networking, optional
Protocol	ISO/IEC 14443A	Camera	Front: 5MP (FF) Rear: 13MP with PDAF+ LED Flash
Reading range	3-5cm	Battery	3.7V/10000mAh
RFID		Communication
Protocol	ISO/IEC18000-6B, 6C / EPC Global C1Gen2/V2	Input/Output	USB Type-C/ OTC
Antenna	Circular 4 dBi	Wi-Fi	802.11 a/b/g/n/ac (2.4GHz+5GHz)
Output Power	0-33dBm adjustable	Bluetooth	BT5.0(BLE)
Frequency	FCC: 902-928MHz ETSI: 865-868MHz More optional	2G/3G/4G	GSM/CDMA/CDMA-EVDO/ TD-SCDMA/WCDMA/TDD LTE/FDD LTE
Bandwidth	＜200KHz	GPS	GPS/AGPS/Glonass/ Beidou
Reading Width	0-15m suggested	Technical support
Anti-collision	Intensive tags / fast inventory supportable	For developers	API, SDK, Software, Doc
Work Mode	Fixed frequency/ hopping	For operators	User manual
Reading Speed	>400tags/sceond	For After sales	Troubleshooting guidance
Barcode/QR code scanner		Environment
Scan Engine Imager	T20 or Imported Brand optional	Operating Temp.	-20 - +50°C
Optical Resolution	5mil or 3mil optional	Storage Temp.	-30 - +60°C
Scanning speed	50 times/s	Humidity	5-95% non-condensing
Code type	PDF417, MicroPDF417, Data Matrix, Data Matrix InverseMaxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse	Sealing	IP65, 150cm free drop, Power on status
Code type		Power supply	DC 5V 2A/3A
